Crossworx Lite 290 MK2
Trail & All Mountain
LITE MK2
29’’ Wheels | 130 mm travel
The short-travel trail bike LITE MK2, featuring 130 mm of rear travel, takes the edge off even the most technical mid-mountain trails. Efficient on the climbs, confident on the descents, and ready for long days in the saddle.
130 mm progressive travel
Our short-travel trail rocket features 130 mm of rear travel at the heart of the LITE frame.
Paired with a 210 × 50 mm shock, the rear suspension delivers 130 mm of finely tuned, progressive travel.
The result is a bike that feels light-footed, agile, and playful — efficient when accelerating, composed on technical trails, and offering exactly the right amount of reserves a modern trail bike demands.
*All Frames are order only and can take 4-8 weeks, see below for details
*Currently we are only providing frames from Crossworx, but complete builds can be arranged.
*Our default shock option is either a Formula MOD coil or Nebbia air shock. But other shocks can be arranged on request. We can provide a deal on a Selva fork to match.
Available in radiant raw and 8 standard colours. Special colour variants are available upon request for an upcharge of $300.-
RADIANT RAW: take note, this really is raw. It is not a brushed or polished or clear coated raw. It is as the frame is after heat treatment and final BB and head tube facing. it will show all the imperfections of raw tubing and different shades of the raw aluminium material. This is really for those that love that RAW and industrial look. But also ideal if you want to brush or polish it your self.
8 standard colours:
- Yawning yellow
- Peaceful Petrol
- Racing Blue
- Vivacious Violet
- Beaming Black
- Gritty Grey
- Obese Orange
- Grassfresh Green
Note on stock and delivery times:
For any frame not in stock take note for delivery times: Crossworx lay out their production plan on the last day of the month for all ordered frames in that month and produce the ordered frames in the following month so frames can be ready at the end of that month for shipping. Shipping from Germany is approx 4 weeks. So if we order a frame at end of the month, expect turn around time to be just over 8 weeks. Any frame not in stock: 8 - 12 weeks (sometimes shorter, contact us!)
Specifications
| Material | Aluminium 7020 |
| Travel front / rear | 140mm oder 150mm / 130mm |
| Shock | 210×50 – 55 mm / 22,2x8mm |
| seat tube diameter | 30,9mm |
| Minimum insertion seatpost | 100mm |
| seat clamp diameter | 34,9mm |
| Headset | ZS 44/56 |
| Bottom Bracket | BSA 73mm |
| Brake | PM 180 |
| max. brake disc size | 203 mm |
| Rear hub width | 12 x 148 mm |
| SRAM UDH Ready | Yes |
| Bottle cage | 2 x |
| ISCG05 | Yes |
| Dropper Post Ready | Yes |
| Fidlock Ready | Yes |
| Max tire width | 29″ x 2,5″ |
| Weight (Raw, Size M) | 3,8 Kg |
| Weight Complete Bike (Raw, Size L, Standard Configuration) |
14,3 Kg |
Geometry
| S | M | L | XL | |
| Body Height | 155 – 167,5 cm | 165 – 177,5 cm | 175 – 187,5 cm | 185 – 197,5 cm |
| A – Horizontal Tube Length | 524 | 554 | 586 | 618 |
| B – Reach | 415 | 445 | 475 | 505 |
| C – Steering Angle | 66° | |||
| D – Seat Angle | 79° | |||
| E – Head Tube Length | 110 | 110 | 120 | 130 |
| F – Chain Stay Length | 455 | |||
| G – Wheel Base | 1184 | 1214 | 1248 | 1282 |
| H – Bottom Bracket Drop | 40 | |||
| I – Seat Tube Length | 405 | 405 | 445 | 465 |
| J – seatpost offset | 12 | |||
| K – Fork Length | 551 | |||
| L – Stack | 625 | 625 | 634 | 643 |
| M – Standover | 797 | 798 | 799 | 799 |
| max. seatpost insert | 224 | 224 | 264 | 288 |
*All dimensions in mm unless otherwise stated, based on a 551 mm fork length
